itel 3.6kw Inverter Hybrid 24V IP31 1Phase IPV-3K624S

The iTel 3.6kw Hybrid Inverter (3.6kW/24V) IPV-3K624S combines solar, grid, and battery power with 99.5% MPPT efficiency and 92% battery conversion efficiency. Featuring intelligent load recognition, 100A fast charging, and 10ms UPS switchover, it’s ideal for home backup, off-grid systems, and energy savings. Certified IP31 with LiFePO4/lead-acid compatibility.

itel 3.6kw Solar Inverter Hybrid 24V

iTel IPV-3K624S Hybrid Inverter – 3.6kW/24V

Key Features:
 Ultra-Efficient MPPT – 99.5% tracking efficiency maximizes solar harvest.
 Seamless Backup – 10ms switchover ensures uninterrupted power during outages.
 High Power Output – 3.6kW continuous (5.7kW surge), supports 2HP motors.
 Fast Charging – 100A charging current for rapid battery replenishment.
 Smart Load Recognition – Auto-adapts to household appliances for optimal performance.
 Dual Battery Support – Compatible with LiFePO4 and lead-acid (21V–30.5V range).

Technical Specifications:

• PV Input: 5,000W max | 500V VOC | 18A current (1 MPPT tracker).
• AC Output: 220/230/240VAC | 16A | <3% THD.
• Battery: 24V system | 156A max discharge current.
• Efficiency: 92% battery mode | 99.5% MPPT.
• Dimensions: 595×285×420mm | Weight: 64kg.

Certifications & Protection:

• Safety: IEC62109, IP31 rated, surge/overload/short-circuit protection.
• Compliance: CE, RoHS, UN38.3.

Ideal For:

• Solar self-consumption systems
• Home backup power (UPS functionality)
• Off-grid cabins/RV setups
• Reducing electricity bills with grid-shaving
