Itel 550W Solar Panel Half Cut Monocrystalline
Brand
itel
Special Price
NGN 137,000.00
Regular Price
NGN 148,000.00
In stock
SKU
ITL-IPS144550-W
itel 550W Solar Panel Half Cut Monocrystalline
| Model Type |
ODA550-36V-MH |
|---|---|
| Peak Power (Pmax) |
550.00 |
| Maximum Power Voltage (Vmp) |
41.50 |
| Maximum Power Current (Imp) |
13.26 |
| Open Circuit Voltage (Voc) |
50.21±3% |
| Short Circuit Current (Isc) |
14.00±3% |
| Module Efficiency (%) |
21.29V |
| Maximum System Voltage (V) |
1500 |
| Maximum Series Fuse Rating (A) |
20 |
| Operational Temperature |
-40-+85°C |
| Nominal Module Operating temp (NMOT) |
-45+2°C |
| Temp Coefficient Of Pmax |
-0.300%/°C |
| Temp Coefficient Of Voc |
-0.260%/°C |
| Temp Coefficient Of Isc |
-0.047%/°C |
| Number of Modules Per Pallet |
37 |
| Number of Pallets per Container |
20 |
| Number of Modules Per Container |
740 |
| Cell Type |
182*91 N-Type Mono |
| No. of Cells |
144 (12*12) |
| Dimensions |
2278*1134*30mm |
| Weight |
27.40kg |
| Front Glass |
3.2mm AR Coating, Tempered Glass |
| Frame |
Anodized Aluminum Profile (Silver) |
| Junction Box |
IP68, 1500VDC, 3 Schottky Bypass Diodes |
| Output Cable |
4.0 square millimeters, positive pole (+) 350 mm, negative pole (-) 350 mm (connectors included), or custom lenghts. |
| Class of Safety Protection |
Class II |
| Max Wind Load / Snow Load |
Class C |
| Connector |
IP68 |
| Product Name | Itel 550W Solar Panel Half Cut Monocrystalline |
|---|---|
| Visibility | Catalog, Search |
| Color | White |
| Manufacturer | itel |
