itel 12kW Inverter Hybrid 48V IP54 1Phase IPV-12K48U

Brand

itel

Be the first to review this product

Special Price NGN 1,325,493.00 Regular Price NGN 2,256,493.00

In stock

SKU

IT-IPV-12KL1

itel 12kW Inverter Hybrid 48V IP54 1Phase IPV-12K48U

Details

More Information

Reviews

Manufacture

The iTel IPV-12K48U Hybrid Inverter (12kW/48V) delivers industrial-grade power with ≥99% MPPT efficiency, 24,000W surge capacity, and IP54 protection. Featuring 15ms UPS switchover, parallel support for 16 units (192kW total), and 200A charging current, it’s engineered for large commercial installations, microgrids, and heavy-duty backup. Backed by a 5-year warranty.

itel 12kw Inverter Hybrid 48V IP54 1Phase IPV-12K48U

iTel IPV-12K48U Hybrid Inverter – 12kW/48V

Key Features:
Industrial Power Output – 12kW continuous (24kW surge) with 200% overload capacity
Military-Grade Durability – IP54 rated enclosure (-25°C to +60°C operation)
Unmatched Scalability – Parallel up to 16 units for 192kW total capacity
Ultra-Fast Charging – 200A MPPT charging current with dual PV inputs
Smart Grid Interaction – Zero-export mode for compliance + generator synchronization
Future-Proof Tech – Built-in WiFi/GPRS for remote monitoring & firmware updates

Technical Specifications:

PV Input: 18,000W max | 600V VOC | Dual MPPT trackers (11A+22A)
AC Output: 220/230/240VAC | <2.5% THD | 50Hz/60Hz
Battery: 48V system (42V–58.4V) | 250A max discharge current
Dimensions: 310×610×218mm | Weight: 28kg

Certifications & Warranty:

Safety: IEC62109, VDE-AR-N 4105, CE, UN38.3
Protection: Anti-islanding, DC/AC surge, over-temperature
Warranty: 5-year limited warranty

Ideal For:

Commercial/industrial solar farms
Hospital/data center backup
Off-grid microgrid systems
EV charging station support

Keyword Focus Tags

Primary Keywords:
- iTel 12kW Hybrid Inverter
- 48V Commercial Inverter
- IPV-12K48U Inverter
- Industrial Solar Inverter
Performance Keywords:
- 24,000W Surge Power
- Parallel 16 Units
- 200A Charging Current
- Dual MPPT Tracking
Application Keywords:
- Microgrid Power System
- Data Center Backup
- Three-Phase Ready Inverter

Weight	151203466444.7 kg
Dimensions	12 × 34.66 × 44.47 cm
Model Type	IPV-12K48U
MPPT Tracking Efficiency	99.5%
Max. Battery Mode Conversion Efficiency	95%
Max. PV Input Power	16000W
Max. PV Input Voltage	500V
Start-Up Voltage	75V
MPPT Voltage Range	85V~450V
Max. Input Current	27A
MPP Trackers	2
Max. Grid Input Voltage	380Vrms
Nominal Voltage	220VAC/230VAC/240VAC
Input Voltage Range	90~280VAC
Max. AC Input Current	90A (by pass)
Nominal Operating Frequency	50Hz/60Hz
THDi	<3%
Nominal AC Output Power	12kW / 12000W
Max. Output Apparent Power	12KVA / 12000VA
Nominal AC Output Voltage	220/230/240VAC
Total Voltage Harmonic Distortion	<3%
Nominal AC Frenquency	50Hz
Switch Time	10mS(UPS);20mS(Applicances)
Surge Power	24000VA @ 5s / 24KVA @ 5s
Overload Capacity	105%-150%@10S,150%-200%@5S
Battery Type	Lead-acid/Li-ion/User Defined
Rated Voltage	48V
Battery Voltage Range	40V-60V
Max. MPPT Charging Current	210A
Max. Mains/Generator Charging Current	210A
Max. Discharging Current	250A
Dimensions DWH (mm)	125mm525mm630mm
Net Weight	28.5kg
Operating Temperature Range	-10-55℃, >45℃ Power Derating
Max. Operating Altitude	4000m, >2000m Power Derating
Communication	WIFI/RS485/CAN/RS232/Dry Contact
Diesel Generator Support	Yes, External Contactor
Dry Contact Support	Yes
Number of Parallel	1Phase: 6 3 Phase: 12
Cooling Method	Intelligent Fan Cooling
Noise	<60dB
Authentication Level	IEC62109-1, IEC62109-2, IEC61683
Ingress Protection	IP54
Overvoltage Protection	Yes
Overload Protection	Yes
Short Circuit Protection	Yes
Smart Load Support	Yes, External Contactor
Over Temperature Protection	Yes
Surge Protection	DC: TypeIII, AC: TypeIII
